500 Kg/H Toilet Soap Finishing Line
Description
This toilet soap production line can make both bath soap and laundry soap. This soap making equipment produces diverse shapes of solid color toilet soaps with fatty acid content of 75-81%. Maximum weight of finished soap is 50g-150g. Productive capacity of this soap equipment is 500 kg per hour. Functions of this toilet soap production line include mixing, refining, extruding, cutting, stamping and molding. This line is equipped with excellent cooling system, advanced special screws, full-automatic freezing stamping machine and high strength transmission mechanism. This toilet soap production line passes the French BV certification.
Features and Advantages
1. Automatic batching system is adopted to avoid batching error caused by manual work.
2. Toilet soap production line also offers complete automation of saponification and neutralization which is realized by using highly sophisticated sensors, flow indicators controllers, high-accuracy dosing pumps and PLC.
3. The line also includes high gear online mixers where 80% process is completed.
4. This bath soap equipment has simple structure and occupies small space.
5. This equipment is easy to operate and it has low energy consumption.
6. There are less fault points in this toilet soap production line. It is reliable and durable.
Use and Maintenance
1. Clients are suggested to keep every device in this soap making equipment clean and lubricate each device regularly according to the instructions.
2. Please pay attention to voltage stability for each device and make sure that ground wires of all devices are unobstructed.
3. This toilet soap production line has a two year warranty period. We provide quick-wear parts in this period. We offer to send technicians to clients as guide for installation, commissioning and training of soap manufacturing.
Parameters of this Toilet Soap Production Line
| Component Name |
Model |
Power |
Rotating Speed |
Notes |
| Mixer |
500S-350Z |
5.5+5.5=11 kW |
A Shaft: 22 rpm B Shaft: 36 rpm |
|
| Triple-Roller Mill |
500S-260 |
7.5 kW |
A Shaft: 15 rpm B Shaft: 45 rpm C Shaft: 135 rpm |
|
| Simplex Refiner |
500S-DR-200 |
11+11 kW |
18 rpm |
Screw Diameter: 200 mm |
| Duplex Plodder |
500S-DRVP-200 |
11+11+2 kW |
Upper Screw :18 rpm Lower Screw: 5-18 rpm |
Screw Diameter: 200 mm |
| Cutting Machine |
500S-QKI |
4 kW |
50-220 times per minute |
|
| Stamping Machine |
500S-MFS-2 |
2.2 kW |
5-45 times per minute |
|
| Cartoner (Packager) |
XZB-200 |
3 kW |
15-180 times per minute |
|
| Water Chiller |
|
5 PH |
|
|
| Freezer |
|
5 PH |
|
|
Packaging & Delivery
This toilet soap production line is packed in wooden boxes (1× 40`FCL and 1 × 20`FCL). It is delivered by automotive at home and by ship overseas.
